Power measurement range – pass zone

1310 nm

5.5 to –15

for continuous data stream (dBm)

1490 nm

1 to -33

1550 nm

15 to -36

Burst mode measurement capability:

Splitter to ONT

Burst mode measurement range b (dBm)

1310 nm

5.5 to -15

Pass through insertion loss b (dB)

1.5

Spectral passband (nm)

1310 nm

1260 to 1360

1490 nm

1480 to 1500

1550 nm

1539 to 1565

Power uncertainty at calibrated

0.5

wavelengths b, d (dB)

Refresh rate of display (Hz)

2.5

Calibrated wavelengths (nm)

1310, 1490, 1550

1310, 1490, 1550

Threshold sets

10 configurable threshold sets

 with threshold naming

Autonomy b (hours)

> 30

Number of ports

1
