Voltage outputs: 1 each: 0 to +25 Vdc @ 0-1
A; 0 to -25 Vdc @ 0-1 A; 0 to 6 Vdc @ 0-5 A
- Ripple &
noise (voltage/rms peak-peak/current rms): <350 µV/2 mV/<500 µA
- Voltage
accuracy: 0.05% +20 mV
- Load
regulation: <0.01% + 2 mV; <0.01% + 250 µA
- GPIB and
RS-232 interfaces
- 115 Vac
±10%; 47-63 Hz operation
- Weight:
15 lb; Size: 132 mm (5.2 in)H x 213 mm (8.4 in)W x 348 mm (13.7 in)D
|
|
